Genuine Dell Fan, Dimension 8200 CPU Case Cooling Fan, W0101, Temperature Control, 92mm x 38mm with Dell 3-pin connector.
Some Dell Dimension 8200 Desktop Computers came with the JMC DATECH 9238-12HBTL-A Cooling Fan as Original Equipment and as Direct O.E. replacement on certain upgraded machines.
For this application is a Dell 3-pin, 92mm x 38mm, 12 Volt, Temperature Control fan with the Heat Sensor and is made to work in Dell Dimension 8200 computers.
*Some select Dell computers came equipped with 92mm x 38mm Dell 3-pin connector as well as 92mm x 32mm and 92mm x 38mm fans with 5-pin/4-wire connectors on upgraded models. This fan for sale has a Dell 3-pin/3-wire connector.
Also, check the wire colors and their respective positions in the Dell 3-pin plug on your old fan compared to the new one you are contemplating on purchasing. The typical wire color order for the Dell 3-pin plug is (latch facing you) white, red and black.
However, if the white and red wires on your old fan plug are (red, white and black) reverse, then the wire positions on the new fan plug will need to be swapped out to match the old one. This was a revision from Dell on their select upgraded systems. Neglecting to make this change will result in component and system board failure. If you are unable to perform this modification, please contact us to make the change for you before shipment. There is no charge for this service. These various fans are available for sale under different listings.
NOTE: Please take measurements, check fan application, compatibility and verify fan plug configuration before making your purchase. See specifications and photos for comparison.
Restore your Dell Dimension 8200 computer to its original condition with this High Quality fan from Genuine Dell Fans.
Reminders, if applicable to your model, avoid the inconvenience of down time, by checking the Rubber Insulator Mounts before making your fan purchase. They are not included with the fan and do not always need replacement. Rubber Insulator Mounts are optional and available for sale on the site. Bring up the listing by typing Rubber Insulator Mounts into the site's search Box.
Genuine Dell Fan Dimension 8200, W0101, Temperature Control, CPU Case Cooling Fan, 92mm x 38mm with Dell 3-pin connector in stock.
Specifications:
. Condition: New
. Mfr: JMC/DATECH
. P/N: DS9238-12HBTL-A
. Size: 92mm x 92mm x 38mm
. Type: Temperature Control with Heat Sensor
. Voltage: DC 12V
. Voltage Range: 10.8-13.2V
. Rated Current: 2.30 A
. Speed: 5700 RPM
. Air Flow: 120 CFM
. Noise Level: 53.2
. Bearing: Dual Ball
. Wire Length: 11"
. Connector: Dell 3-pin
